SafyrOPC
SafyrOPC is a portable or fixed, ready-to-use solution for real-time particle monitoring in cleanrooms, laminar flow hoods, and biosafety cabinets. Combining the SafyrOPC optical particle counter (ISO 21501-4 calibrated) with its LoRa gateway, allows teams to perform fast, reliable self-checks before regulatory audits. Resistant to H₂O₂ decontamination and offering up to 168 hours of battery autonomy, the SafyrOPC device ensures continuous, compliant monitoring for GMP facilities and ISO 14644 environments, reducing downtime, costs, and compliance risks.
> Specifications
> Got to TERA Sensor Knowledge platform
User guide, Windows Software, 3D STEP files, Firmware history…
Specifications
Count channels
0.5 to 2.5µm
Smallest channel measured by SafyrOPC Sensor
0.3 µm
Limit concentration
8500 000 part/ft3
Direct debit:
2.83 l/min (0.1 cfm)
Sampling flow error
+/- 10%
High efficiency filtration at discharge:
patented
Accelerometer
Yes
Sampling Time / Sample Volume:
Cumulative 10 minutes moving average/ 28.3 l
Update frequency
1 minute
Unit
Particles per Cubic Feet (Part/CF)
Calibration
Monodisperse latex sphere (NIST certificate) - ISO 21501-4 calibration bench
Counting efficiency: Manufacturer
Channel 0.3µm: (35 +/- 15) %
Channel 0.5µm: (100 +/- 20) %
Counting efficiency: Using Lyra (Corrected )
Channel 0.3µm: (5 +/- 20) %
Channel 0.5µm: (100 +/-10) %
Statistical rate of false counting (All Channels ≥ 0.3 µm):
≤ 70.7 part/m³ or ≤ 2 part/CF³
Power
On batteries or mains 5VDC - 1A
Energy Block SB Model:
Autonomy (O mains): 12h - LiPo battery 3.7V 4.5Ah
Energy Block Model AB168
Autonomy (O mains): 168h - 3.7V 18Ah LiPo battery
Communication
Propriate LoRa
Frequency range
869.5 MHz / 2.4 GHz
Number of channels available (1 receiver per ID)
5
Propriate LoRa (869,5 MHz)
<400m free field /5.50m indoor
Decontamination
Materials compatible with surface disinfectants by wiping. Resistant to H2O type airborne
Environmental conditions of use
Temperature: 5-35°C/Humidity: 0-70% (Not condensed)
Size
Height: 147 mm / Diameter: 103mm
Weight
SafyrOPC with Energy block SB: 420 g
SafyrOPC with Energy block AB168: 720 g
Case material
White part: ABS-PC/ Di using part: PC
SafyrOPC delivered with:
HEPA H14 filter - isokinetic probe - Power Cord
Operating instructions - Installation certificate - Calibration certificate
