PMSCAN datasheet
PARTICULATE MATTER PERSONAL EXPOSURE MONITORING
| Designation | Values |
|---|---|
| GENERAL | |
| Measured parameters | PM₁/PM₂.₅/PM₁₀ in µg/m³ Temperature in °C Relative Humidity in % Battery Level |
| PERFORMANCE | |
| PM Concentration Range | 0 - 1000 µg/m³ |
| Particle Size detection range | 0.3 µm to 10 µm |
| PM Repeatability | < 3% |
| COMMUNICATION | |
| Type | Low consumption radio communication |
| Measure/ Transmission Frequency | From 1 second up to 5 minutes |
| Communication Options | Moving Average 10 - 60 - 900 sec |
| ENERGY | |
| Power | USB C 5 V (+/- 10%) - 1A. Do not apply voltage over 13V at the risk of destroying the sensor |
| Battery life Normal Mode | 15 hours |
| Eco Mode | > 20 hours |
| MEMORY | |
| Internal memory | Data acquisition 6145 points (total duration depending on frequency) |
| DIMENSIONS / WEIGHT | H 88 mm x L 76 mm x P 36 mm | 210 gr |
